| Materials |
Exterior: SPCC
Side Panel: Right Panel - Steel |
| Dimensions |
430mm(L) x 295mm(W) x 390mm(H) (Incl. Protrusions)
415mm(L) x 295mm(W) x 368mm(H) (Excl. Protrusions) |
| Motherboard Support |
ITX/M-ATX/ATX(without bottom radiator installed) |
| Expansion Slots |
6 |
| Drive Bays |
3.5” HDD: 2
2.5” SSD: 2 |
| I/O Panel |
USB 3.2 Gen1*2, USB 3.2 Gen2*1
Single Audio jack |
| Pre-installed Fan(s) |
Rear: 1 x CF120 ARGB
Front: N/A
|
| Fan Support |
Motherboard tray: 2 x 120mm
Top: 3 x 120mm/2 x 140mm
Bottom: 3 x 120mm/2 x 140mm
Rear: 1 x 120mm/1 x 140mm
|
| Radiator Support |
Motherboard tray: 240mm
Top: 240mm/280mm/360mm
bottom: 240mm/280mm/360mm
|
| Clearances |
CPU Cooler: 175mm
Power Supply: Max.200mm
Graphics Card: Max.400mm
|
| Cable Routing |
Behind MB Tray: 57mm
|
| Dust Filters |
Top/Bottom
|
| Power Supply Support |
SFX/SFX-L/ATX
|
