Model
|
ROG Thor 1200W Platinum III
|
|
Intel Specification
|
ATX12V
|
|
PFC Type
|
Active PFC
|
|
ATX Standard
|
ATX 3.1
|
|
Dimensions
|
190 x 150 x 86 mm
|
|
Efficiency
|
80Plus Platinum
|
|
MTBF
|
>120,000 hrs @ 25°C
|
|
Protection Features
|
OPP/OVP/UVP/SCP/OCP/OTP
|
|
Hazardous Materials
|
ROHS
|
|
AC Input Range
|
100-240Vac
|
|
DC Output Voltage
|
+3.3V +5V +12V -12V +5Vsb
|
|
Maximum Load
|
30A 25A 100A 0.3A 3A
|
|
Combined Load
|
125W 125W 1200W 3.6W 15W
|
|
Total Output
|
1200W
|
|
Cable Connectors
|
MB 24/20-pin x 1
CPU 4+4-pin x 2
PCI-E 16-pin x 1
PCI-E 6+2-pin x 4
SATA x 7
PERIPHERAL x 6
|
|
Package Contents
|
Power Cord x 1 Motherboard Power Cable x 1 (610mm) CPU Cable x 2 (1000mm) PCI-E Gen 5.1 16-pin Cable x 1 (750mm) PCI-E Cable 1-to-1 x 4 (750mm) SATA Cable 1-to-4 x 1 (400+120+120+120mm) SATA Cable 1-to-3 x 1 (400+120+120mm) Peripheral 1-to-3 x 2 (400+150+150mm) Addressable RGB Cable x 1 (800mm) ROG sticker x 1 ROG cable tie x 6 Chassis Screws Package x 1 Cable Tie x 12 User Manual x 1
|
|
Weight
|
2.37 KG (single PSU)
|
|
AURA SYNC
|
ARGB
|
|
Cybenetics Noise Level Certification
|
TBD
|
|
0dB Technology
|
Supported. The fan shuts off entirely when the PSU is under certain load
|
|
0dB Fan Button
|
Yes. When the Button is ON, the fan will only spin up when the system reaches a certain load. When the Button is OFF, the fan will continuously spin at all load levels.
|
