Model No. |
SST-ST1200-PTS
|
Max. DC Output |
1200W
|
Power density |
664W per liter
|
Load Range
|
|
+3.3V |
+5V |
+12V |
+5VSB |
-12V |
Max.(Amps)
|
25A |
22A |
100A |
3A |
0.3A |
Min.(Amps)
|
0A |
0A |
0.15A |
0A |
0A |
Range (%)
|
±3% |
±3% |
±3% |
±5% |
±10% |
Line Reg.(%)
|
±1% |
±1% |
±1% |
±1% |
±1% |
Ripple(mVp-p)
|
50mV |
50mV |
120mV |
50mV |
120mV |
|
Color |
Black(Lead-Free Paint)
|
Combined +3.3V & +5V |
120W
|
Combined +12V |
1200W
|
Input Voltage |
100V~264V
|
Input Frequency Range |
47Hz~63Hz
|
PFC |
Active PFC(PF>0.9 at full load)
|
Efficiency |
89%~92% at 20%~100% loading
|
MTBF |
100,000 hours
|
Operating temperature |
0°C ~ 40°C
|
Protection |
Over power protection
Over current protection
Over voltage protection
Over Temperature protection
Under voltage protection
Short circuit protection
|
Connectors |
1 x 24 / 20-Pin motherboard connector(”600mm”)
1 x 8 / 4-Pin EPS / ATX 12V connector(”550mm”)
1 x 8 / 4-Pin EPS / ATX 12V connector(”750mm”)
8 x 8 / 6-Pin PCIE connector(”550mm/150mm” X4)
8 x SATA connector("600mm /150mm / 150mm / 150mm" X2)
6 x 4-Pin Peripheral connector(”600mm / 150mm / 150mm” X2)
2 x 4-Pin Floppy connector(”150mm” X2)
|
Cooling System |
Single 120mm HYB fan
|
Form factor |
ATX
|
Noise Level |
18 dBA minimum
|
Dimension |
150 mm (W) x 86 mm (H) x 140 mm (D)
5.91" (W) x 3.39" (H) x 5.51" (D)
|
Weight |
2kg
|
Certification |
80 PLUS Platinum
|
Other |
GPU Support list
Compatible with ATX12V v2.4
|
