PRODUCT NUMBER
MLX-D36M-A18PK-R1
EXTERIOR COLOR
Black
CPU SOCKET
LGA2066, LGA2011-v3, LGA2011, LGA1200, LGA1151, LGA1150, LGA1155, LGA1156, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1
RADIATOR MATERIAL
Aluminum
RADIATOR DIMENSIONS
394 x 119.6 x 27.2 mm / 15.5 x 4.7 x 1.1 inch
PUMP DIMENSIONS
81.2 x 76 x 57.8 mm / 3.19 x 3 x 2.3 inch
PUMP MTTF
70,000 Hours
PUMP NOISE LEVEL
< 10 dBA
POWER CONNECTOR
3-Pin
PUMP RATED VOLTAGE
12 VDC
PUMP POWER CONSUMPTION
2.36 W
FAN DIMENSIONS (L X W X H)
120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch
FAN QUANTITY
3 PCS
FAN LED TYPE
Non-LED
FAN SPEED
650-1800 RPM ± 5%
FAN AIRFLOW
62 CFM (Max)
FAN NOISE LEVEL
8 - 27 dBA
FAN PRESSURE
2.5 mmH₂O (Max)
FAN LIFE EXPECTANCY
160,000 Hours
FAN POWER CONNECTOR
4-Pin (PWM)
FAN RATED VOLTAGE
12VDC
FAN RATED CURRENT
0.15A
TDP
280 W
RAM CLEARANCE
N/A
WARRANTY
2 years
SERIES
MasterLiquid
COOLER TYPE
Liquid Cooler
RADIATOR SIZE
360
