Mainboard Asus ROG STRIX B860-I GAMING WIFI DDR5 (Thunderbolt4+Bluetooth)

• Tên Hãng

• ASUS

• CPU hỗ trợ

• Support Intel Core Ultra Processors (Series 2)
• Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0

• Chipset

• Intel B860 Chipset

• RAM hỗ trợ

• 2 x DIMM slots, max. 128GB, DDR5
• Supports up to 9066+MT/s (OC), Non-ECC
• Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*
• Dual channel memory architecture
• DIMM Fit
• Supports Intel® Extreme Memory Profile
• (XMP) memory module
• ASUS Enhanced Memory Profile III (AEMP III)

• Đồ họa

• 1 x DisplayPort
• 1 x HDMI port
• 1 x Intel Thunderbolt 4 supports
• DisplayPort and Thunderbolt video outputs

• Khe cắm mở rộng

• Intel Core Ultra Processors(Series 2)
• 1 x PCIe 5.0 x16 slot

• Ổ cứng hỗ trợ

• Supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
• Intel Core Ultra Processors(Series 2)
• M.2_1 slot (Key M), type 2260/2280 (supports PCIe 5.0 x4 mode)
• Intel B860 Chipset
• M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
• 4 x SATA 6Gb/s ports

• ETHERNET

• 1 x Intel 2.5Gb Ethernet
• ASUS LANGuard

• USB

• Rear USB (Total 8 ports)
  • - 1 x Thunderbolt 4 port (1 x USB Type-C)
  • - 1 x USB 20Gbps port (1 x USB Type-C)
  • - 1 x USB 10Gbps ports (1 x Type-A)
  • - 3 x USB 5Gbps ports (3 x Type-A)
  • - 2 x USB 2.0 ports (2 x Type-A)

• Front USB (Total 5 ports)
  • - 1 x USB 10Gbps connector (supports USB Type-C)
  • - 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
  • - 1 x USB 2.0 header supports 2 additional USB 2.0 ports

• Cổng kết nối (Internal)

• Fan and Cooling Related
  • - 1 x 4-pin CPU Fan header
  • - 1 x 4-pin AIO Pump header
  • - 1 x 4-pin Chassis Fan headers

• Power Related
  • - 1 x 24-pin Main Power connector
  • - 1 x 8-pin +12V CPU Power connector

• Storage Related
  • - 2 x M.2 slots (Key M)
  • - 4 x SATA 6Gb/s ports

• USB
  • - 1 x USB 10Gbps connector (supports USB Type-C)
  • - 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
  • - 1 x USB 2.0 header supports 2 additional USB 2.0 ports

• Miscellaneous
  • - 2 x Addressable Gen2 headers
  • - 1 x Front Panel Audio header (F_AUDIO)
  • - 1 x 10-1 pin Front System Panel header
  • - 1 x Thermal Sensor header

• Cổng kết nối (Back Panel)

• 1 x Thunderbolt 4 port (1 x USB Type-C)
• 1 x USB 20Gbps port (1 x USB Type-C)
• 1 x USB 10Gbps ports (1 x Type-A)
• 3 x USB 5Gbps ports (3 x Type-A)
• 2 x USB 2.0 ports (2 x Type-A)
• 1 x DisplayPort
• 1 x HDMI port
• 1 x Wi-Fi module
• 1 x Intel 2.5Gb Ethernet port
• 2 x Audio jacks
• 1 x Optical S/PDIF out port
• 1 x Clear CMOS button

• LAN / Wireless

• Wi-Fi 7
• 2x2 Wi-Fi 7 (802.11be)
• Supports 2.4/5/6GHz frequency band
• Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.
• Bluetooth v5.4

• Âm thanh

• Realtek ALC1220P 7.1 Surround Sound High
• Definition Audio CODEC
  • - Impedance sense for front and rear
  • headphone outputs
  • - Internal audio Amplifier to enhance the
  • highest quality sound for headphone and speakers
  • - Supports: Jack-detection,

• Multi-streaming, Front Panel Jack-retasking
  • - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
  • - Supports up to 32-Bit/192 kHz playback

• Audio Features

- SupremeFX Shielding Technology

- Savitech SV3H712 AMP

- Rear optical S/PDIF out port

- Premium audio capacitors

- Dedicated audio PCB layers

• Kích cỡ

• Mini-ITX Form Factor
• 6.7 inch x 6.7 inch ( 17 cm x 17 cm )
